Cutting wheels and pinions

Gearwheel cutters

With only 26 HHS universal burs you can now cut all wheels with 25 or more teeth for all modules yourself.

Subgroups

Cutting machine

name Version manufacture item No.
Cutting machine Gears and drives Bergeon 690240
Extension set for cutting drives Bergeon 690241

wheel cutters flat bottoms

name	Version	modul	outside-Ø	drill-hole Ø	thickness	item No.
wheel cutter	flat tooth base	0.20	22.0mm	7.00mm	2.00mm	515020
wheel cutter	flat tooth base	0.25	22.0mm	7.00mm	2.00mm	515022
wheel cutter	flat tooth base	0.30	22.0mm	7.00mm	2.00mm	515023
wheel cutter	flat tooth base	0.35	22.0mm	7.00mm	2.00mm	515025
wheel cutter	flat tooth base	0.40	25.0mm	7.00mm	3.25mm	515027
wheel cutter	flat tooth base	0.45	25.0mm	7.00mm	3.25mm	515028
wheel cutter	flat tooth base	0.50	25.0mm	7.00mm	3.25mm	515030
wheel cutter	flat tooth base	0.55	25.0mm	7.00mm	3.25mm	515031
wheel cutter	flat tooth base	0.60	25.0mm	7.00mm	3.25mm	515033
wheel cutter	flat tooth base	0.65	25.0mm	7.00mm	3.25mm	515034
wheel cutter	flat tooth base	0.70	25.0mm	7.00mm	3.25mm	515036
wheel cutter	flat tooth base	0.75	25.5mm	7.00mm	4.50mm	515038
wheel cutter	flat tooth base	0.80	25.5mm	7.00mm	4.50mm	515039
wheel cutter	flat tooth base	0.85	25.5mm	7.00mm	4.50mm	515041
wheel cutter	flat tooth base	0.90	25.5mm	7.00mm	4.50mm	515042
wheel cutter	flat tooth base	0.95	25.5mm	7.00mm	4.50mm	515044
wheel cutter	flat tooth base	1.00	25.5mm	7.00mm	4.50mm	515045
wheel cutters assortment	17 pieces					515105

wheel cutters round bottoms

name	Version	modul	outside-Ø	drill-hole Ø	thickness	item No.
wheel cutter	round tooth base	0.20	22.0mm	7.00mm	2.00mm	515060
wheel cutter	round tooth base	0.25	22.0mm	7.00mm	2.00mm	515062
wheel cutter	round tooth base	0.30	22.0mm	7.00mm	2.00mm	515063
wheel cutter	round tooth base	0.35	22.0mm	7.00mm	2.00mm	515065
wheel cutter	round tooth base	0.40	25.0mm	7.00mm	3.25mm	515067
wheel cutter	round tooth base	0.45	25.0mm	7.00mm	3.25mm	515068
wheel cutter	round tooth base	0.50	25.0mm	7.00mm	3.25mm	515070
wheel cutter	round tooth base	0.55	25.0mm	7.00mm	3.25mm	515071
wheel cutter	round tooth base	0.60	25.0mm	7.00mm	3.25mm	515073
wheel cutter	round tooth base	0.65	25.0mm	7.00mm	3.25mm	515074
wheel cutter	round tooth base	0.70	25.0mm	7.00mm	3.25mm	515076
wheel cutter	round tooth base	0.75	25.5mm	7.00mm	4.50mm	515078
wheel cutter	round tooth base	0.80	25.5mm	7.00mm	4.50mm	515079
wheel cutter	round tooth base	0.85	25.5mm	7.00mm	4.50mm	515081
wheel cutter	round tooth base	0.90	25.5mm	7.00mm	4.50mm	515082
wheel cutter	round tooth base	0.95	25.5mm	7.00mm	4.50mm	515084
wheel cutter	round tooth base	1.00	25.5mm	7.00mm	4.50mm	515085
wheel cutters assortment	17 pieces					515100

recoil escape cutters

name	radius	outside-Ø	drill-hole Ø	thickness	item No.
recoil escape cutter	3.28mm	26.0mm	7.00mmm	1.64mm	515120
recoil escape cutter	4.10mm	26.0mm	7.00mmm	2.05mm	515121
recoil escape cutter	5.12mm	26.0mm	7.00mmm	2.56mm	515122
recoil escape cutter	6.40mm	26.0mm	7.00mmm	3.20mm	515123
recoil escape cutter	8.00mm	26.0mm	7.00mmm	4.00mm	515124
recoil escape cutter	10.00mm	26.0mm	7.00mmm	4.50mm	515125
recoil escape cutter	12.25mm	26.0mm	7.00mmm	5.80mm	515126

dead beat scape cutters

name	Ø	drill-hole Ø	thickness	item No.
dead beat escape cutter	19.4mm	7.00mmm	2.23mm	515130
dead beat escape cutter	27.9mm	7.00mmm	3.18mm	515131
dead beat escape cutter	36.7mm	7.00mmm	4.20mm	515132
dead beat escape cutter	45.3mm	7.00mmm	5.17mm	515133

straight ratchet cutters

name Tip angle drill-hole Ø thickness item No.
ratchet wheel cutter 60° 7.00mm 7.20mm 515223
ratchet wheel cutter 70° 7.00mm 7.20mm 515224

radiused ratchet cutters

name	Radius of curvature	for ratchet wheel-Ø	Cutter-Ø	drill-hole Ø	item No.
ratchet wheel cutter	4.00mm	8.00mm	20.0mm	7.00mm	515230
ratchet wheel cutter	6.00mm	12.00mm	26.0mm	7.00mm	515231
ratchet wheel cutter	9.0mm	18.0mm	26.0mm	7.00mm	515232
