Elmadry TD
Hot air and cold air drying units - Elmadry TD
To dry the parts again after immersion or ultrasonic baths or rinsing, drying units from the Elmadry TD series are available for drying with cold or hot air.
drying device Previous product3/3Next product
Elmadry - warm air and cold air - drying units
Elmadry drying units for use in the production, workshop and service. After ultrasonic cleaning, the parts are first rinsed in the basket with municipal water and then dipped into a bath of deionized or distilled water (needed for spotless drying).
The basket with the cleaned parts in then placed conveniently placed in the Elmadry TD drying unit. The hot air function is activated while the cover is on. The cover has ventilation slots, ensuring that maximum air turbulence is produced and the moist air is conducted to the outside.
At the same time, the cover reduces energy consumption. The dust filter on the underside is replaceable and prevents re-soilng of the cleaned parts by the dust in the room air.
Technical data:
Tank labour capacity: 20,6 liter
Heating power: 1060 Watt
Temperature: max. 70°C
Unit external dimensions (W x D x H): 540 x 345 x 320 mm
Tank internal dimensions (W x D x H): 500 x 300 x 175 mm
Basket loading: max. 1,0 kg
Basket internal dimensions (W x D x H): 420 x 250 x 300 mm
Weight: 10200g
The basket is not included!
Suitable basket:
3x Type 60 Nr. 691475
1x Type 60 Nr. 691475 + 1x Type 100 Nr. 691485
1x Type 60 Nr. 691475 + 1x Type 120 Nr. 691505
2x Type 100 Nr. 691485
2x Type 120 Nr. 691505
1x Type 300 Nr. 691518
namedrying device
VersionHot-/Cold
output1140 watt
tank size504x300x175 mm
typeElmadry TD300
item No.691367
